The Muirhead® Smart Service Monitor is designed to monitor the work hours of equipment and components to alert the user if the equipment requires or is overdue for a service or component replacement. The Service Monitor can provide both visual and audio alarms to alert the operators.
Due to the extremely robust and intuitive in-built programming tool, the Service Monitor is capable of monitoring service hours of almost anything on your machine and can monitor multiple different types of inputs, including frequency, PWM, and digital or analogue VDC. If you can think of it and provide an input to the device, the Smart Service Monitor can keep tabs on that system for you.
In addition to the monitoring capabilities, the Smart Service Monitor has an internal real-time clock that allows the user to manually set personalised alarms via the on-board buttons for different times of the day.
It utilises Wi-Fi connectivity to allow anyone with a Wi-Fi-capable device e.g. smartphone, tablet PC, or laptop; to quickly and easily configure the device. This connection is also password-protected to prevent unwanted tampering by operators.
| Operating voltage | 11-36V |
| Maximum current consumption (no outputs) | Input voltage and software dependant, absolute max @ 12 V, 116 mA |
| Inputs | Frequency inputs up to 50kHz |
| PWM between 5-95% | |
| Digital/Analogue 0-35 VDC | |
| Weight (controller only) | 200g |
| Operating temperature | −20 ℃ to +60 ℃ |
| Environmental rating | IP65 |
